Before installing your instrument, ensure that the environment meets the following conditions to guarantee optimal performance and long-term stability.

Environmental Conditions

• Temperature: Maintain a room temperature between 20 °C and 30 °C.
• Humidity: Keep relative humidity between 5% and 70%, non-condensing.
• Airflow: Avoid placing the instrument in locations exposed to direct sunlight or air streams from heating/cooling units.

Table Requirements

• The table must support a minimum of 70 kg.
• A free surface area of at least 66 cm (width) × 62 cm (depth) is required.
• The table should be stable and vibration-resistant to avoid instrument movement during operation.

Power Access and Clearance

• Ensure the power plug is easily accessible for plugging in and unplugging the instrument.
• The power switch (located on the lower left of the instrument’s back panel) must be within easy reach.
• Keep the system door and tray area clear of obstructions to allow for smooth opening and closing.

Additional Placement Considerations

• Do not place the instrument near strong magnetic fields or high-frequency sources.
• Avoid exposure to vibrations from equipment such as vacuum pumps, centrifuges, or electric motors.
• Keep the instrument away from dust and corrosive gases.
• Do not place any items or liquids on or near the top of the instrument.
